Phlex Tabs: Multiple Capture Blocks in a Phlex Component
I’ve been exploring Phlex recently, and I’ve been really happy with how easy it is to migrate existing views and components. Phlex has features to cover a lot of the more tricky cases I’ve come across so far, the straightforward architecture allows me to come up with solutions for cases that Phlex doesn’t support out-of-the-box.
One such case is a navigation tabs component. Inspired by the Yielding an Interface section of the documentation, I came up with an implementation that looked something like this (simplified for clarity):
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
class Components::Tabs < Components::Base
def initialize
@tabs = []
end
def view_template(&)
vanish(&)
render_tab_wrapper do
@tabs.each { |tab| render_tab(tab) }
end
render_content_wrapper do
@tabs.each { |tab| render_contents(tab) }
end
end
def tab(title, &content)
@tabs << {title:, content:}
end
private
def render_tab_wrapper(&)
ul(class: "tabs", &)
end
def render_content_wrapper(&)
div(class: "tab-content", &)
end
def render_tab(tab)
li(class: "tab-item") do
button(class: "tab-link") { tab[:title] }
end
end
def render_contents(tab)
div(class: "tab-pane") { tab[:content].call(tab) }
end
end
The view_template method yields itself (via Phlex magic) to the caller, and we call #tab in the block to add a new tab (including the title and tab body) to the tab list. We then iterate that tab list twice: once to render the tabs and once to render the contents. This component could be used like so:
1
2
3
4
5
6
7
8
9
Components::Tabs.new do |tabs|
tabs.tab("Tab 1 Title") do
h1 { "Tab 1 Content" }
end
tabs.tab("Tab 2 Title") do
h1 { "Tab 2 Content" }
end
end
This method worked well, until I needed to include HTML in my tab title. It’s awkward to pass HTML as a string to #tab (and we would need to use Phlex’s raw and safe), and we’re already using the block parameter to capture the tab contents. What I needed was a way to pass in two blocks when calling #tab, one for the title and one for the body. Here’s what I came up with:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
class Components::Tabs < Components::Base
class TabData
attr_reader :title_content, :body_content
def initialize
@title_content = -> { raise "No title content provided" }
@body_content = -> { raise "No body content provided" }
end
def title(&content)
@title_content = content
end
def body(&content)
@body_content = content
end
end
def initialize
@tabs = []
end
def view_template(&)
vanish(&)
render_tab_wrapper do
@tabs.each { |tab| render_tab(tab) }
end
render_content_wrapper do
@tabs.each { |tab| render_contents(tab) }
end
end
def tab(title = nil, &body)
tab_data = TabData.new
@tabs << tab_data
if String === title
tab_data.title { title }
tab_data.body(&body)
else
yield tab_data
end
tab_data
end
private
def render_tab_wrapper(&)
ul(class: "tabs", &)
end
def render_content_wrapper
div(class: "tab-content", &)
end
def render_tab(tab, active)
li(class: "tab-item") do
button(class: "tab-link") { tab.title_content&.call || "" }
end
end
def render_contents(tab, active)
div(class: "tab-content") { tab.body_content&.call || "" }
end
end
The big change here is how the #tab method works. There are now two ways to call this method; we can still use the existing interface, where we pass the tab title as a string and the tab body in the block. However, the internal behaviour has changed: we now create an instance of our new TabData object, which is basically a container for two blocks (or procs, really). We assign the passed-in body block to the new tab_data, create a new block for the title and assign that block to our tab_data as well.
We also introduce a new way to use #tab. If we don’t pass in a title, #tab will yield the tab_data object, allowing the caller to use #body and #title. Now we can capture HTML block for both title and body! An example:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Components::Tabs.new do |tabs|
tabs.tab do |tab|
tab.title do
strong { "HTML Tab 1 Title" }
end
tab.body do
h1 { "Tab 1 Content" }
end
end
tabs.tab do |tab|
tab.title do
strong { "HTML Tab 2 Title" }
end
tab.body do
h1 { "Tab 2 Content" }
end
end
end
Here’s the unabridged component, complete with Bootstrap classes and accessibility inclusions.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
class Components::Tabs < Components::Base
class TabData
attr_reader :title_content, :body_content
attr_accessor :slug
def initialize
@title_content = -> { raise "No title content provided" }
@body_content = -> { raise "No body content provided" }
end
def title(&content)
@title_content = content
end
def body(&content)
@body_content = content
end
end
def initialize
@tabs = []
@slug_seed = rand(36**8).to_s(36).rjust(8, "0")
end
def view_template(&)
vanish(&)
render_tab_wrapper do
@tabs.each_with_index do |tab, index|
active = index.zero?
render_tab(tab, active)
end
end
render_content_wrapper do
@tabs.each_with_index do |tab, index|
active = index.zero?
render_contents(tab, active)
end
end
end
# This method can be called one of two ways:
#
# ```
# Plain text tab title:
# Components::Tabs.new do |tabs|
# tabs.tab("Tab 1") do
# tab_content_goes_here
# end
# end
#
# HTML Tab Title
# Components::Tabs.new do |tabs|
# tabs.tab do |tab|
# tab.title do
# html_title_contents
# end
#
# tab.body do
# body_contents
# end
# end
# end
# ```
def tab(title = nil, &body)
tab_data = TabData.new
@tabs << tab_data
tab_data.slug = @slug_seed + "-" + @tabs.size.to_s
if String === title
tab_data.title { title }
tab_data.body(&body)
else
yield tab_data
end
tab_data
end
private
def render_tab_wrapper
ul(class: "nav nav-tabs", role: "tablist") do
yield
end
end
def render_content_wrapper
div(class: "tab-content") do
yield
end
end
def render_tab(tab, active)
li(class: "nav-item", role: "presentation") do
button(
class: ["nav-link", ("active" if active)],
id: "#{tab.slug}-tab",
role: "tab",
type: "button",
aria: {
controls: "#{tab.slug}-tab-pane",
selected: active.to_s
},
data: {
bs_toggle: "tab",
bs_target: "##{tab.slug}-tab-pane"
}
) { tab.title_content&.call || "" }
end
end
def render_contents(tab, active)
div(
class: ["tab-pane", "fade", ("show active" if active)],
id: "#{tab.slug}-tab-pane",
role: "tabpanel",
aria: {labelledby: "#{tab.slug}-tab"},
tabindex: "0"
) { tab.body_content&.call || "" }
end
end
